Manufacturer 300Mbps with 3*6dBi Antenna Wifi Router password external antenna AC Management

FOB Reference Price:Get Latest Price
  • 1 - 99 Pieces
    US $22.06
  • 100 - 499 Pieces
    US $21.03
  • 500 - 999 Pieces
    US $20.59
  • >=1000 Pieces
    US $19.85
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
EDUP
Model Number:
EP-RT2631
Type:
satellite receiver wifi usb adapter
Ram:
64M
Chipset:
MediaTek7620A
Standard:
IEEE 802.11b/g/n
USB Type:
USb2.0
Transmission Rate:
300Mbps
Function:
Wifi Receiver /Soft Ap
OEM:
Yes
MOQ:
1pcs
Antenna:
3*6dBi
Supply Ability
Supply Ability:
1000000 Piece/Pieces per Month OEM is 1000pcs
Packaging & Delivery
Packaging Details
500pcs/Carton,0.03KG/pc
Port
Shenzhen
Lead Time :
1~3days for ready goods,OEM is 25days

Manufacturer 300Mbps with 3*6dBi Antenna Wifi Router password external antenna AC Management



Model: EP-RT2631

  • wifi router
  • wifi router password

  • wifi router with external antenna

Product Description

802.11b/g/n 300mbps EP-RT2631 integrates 4-port switch with three-5dBi antennas. EP-RT2631provides speedy and stable Wi-Fi for your network needed devices. Up to 300Mbps wireless speed makes it a practical solution for home network applications like files download, video chat or online streaming. Three 5dBi high gain antennas has a better coverage lets you never lost connections and enjoy more stable connection. Parent Control allows parents or administrators to deploy restricted access for children or staff. You can also easily set up a black or white list to limit the level of web access. Guest Network function provides secure access for guests to sharing your Wi-Fi network. Easy sharing, no worry about your private network.



Features

  1. Complies with 2.4GHz IEEE802.11n Draft v2.0 and backward compatible with IEEE 802.11b/g standards
  2. Supports NAT/NAPT IP sharing
  3. WAN Protocols: PPPoE/Static IP/Dynamic IP
  4. High speed data rate - up to 300Mbps.
  5. Supports QoS
  6. Supports 64/128-bit WEP encryption and WPA-PSK, WPA2-PSK security
  7. Working Mode:Wifi Router / AP
  8. Supports Parent Control,MAC Address Filtering
  9. Supports Mult SSID and Anti-ARP attack

Specifications

Standards

IEEE 802.11n(Draft 2.0), IEEE 802.11g, IEEE 802.11b

Chipset

MTK7620A

Frequency Range

2.4-2.4835GHz

SPI Flash

8MB

Ram

DDR2 64M

Receiver Sensitivity

802.11n:-68dBm for 10% PER

802.11g:-74dBm for 10% PER

802.11b:-90dBm for 10% PER

Channel

2.4Ghz:1~13

Translation Rate

300mbps

Frequency range

2.4Ghz

Power

DC Power:12V/1A

Indicator

1 Red 2.4Ghz Power Indicator

1 Green 2.4Ghz Wireless Indicator

1 Green WPS Indicator

1Green USB Indicator

1 Green System Indicator

Button and USB Port

1 Reset Button

1 USB2.0 Port



Frequency Range

2.4GHz:2.4~2.4835GHz

Transmission Rate

2.4GHz Channel

11b:1/2/5.5/11Mbps

11g:6/9/12/18/24/36/48/54Mbps

11n:up to 300Mbps

Working Channel

2.4GHz Frequency:13(1~13)

spread spectrum

DSSS

Data Modulation

11b:CCK,QPSK,BPSK

11g:OFDM

11n:QPSK,BPSK,16-QAM,64-QAM

MAC Protocol

CSMA/CA with ACK

Encryption

WPA-PSK/WPA2-PSK,WPA/WPA2,WEP

Sensitivity

802.11n

802.11g

802.11b

-90dBm for MCS0

- 94dBm for 6Mbps

- 96dBm for 1Mbps

-68dBm for MCS7

- 72dBm for 54Mbps

- 89dBm for 11Mbps

Transmitted Power

802.11n(2.4GHz)

802.11g

802.11b

21dBm for MCS0~2/MCS8~10

23dBm for 6~24Mbps

25dBm for 1~11Mbps

21dBm for MCS3/MCS11

23dBm for 36Mbps



21dBm for MCS4/MCS12

23dBm for 48Mbps



21dBm for MCS5/MCS13

23dBm for 54Mbps



21dBm for MCS6/MCS14





21dBm for MCS7/MCS15







Software Specification

Network Wizard

Self network configuration

Wireless Setup

Chinese SSID

Support SSID



Hidden SSID

Hidden SSID



SSID

Support 3SSID Group



Wireless mode

802.11b/g/n



Channel

1-13



Channel Bandwidth

20/40MHz



Spread Spectrum

Auto



Advanced setting

IGMP, Multicast, preamble, ampdu RTS, RTS, DTIM, Signal Interval, TX Burst, Packet Aggergarion, WMM APSD WMM DLS

Networking Setting

WAN/LAN

Support PPOE dial, Static IP and Dynamic IP. setup address:192.168.10.1

System Setup

Working mode

Wireless Router/AP

System Setup

Router Name, Password, Time server, access authorization, Access mode

Hardware upgrade

Upgrade Hardware

Restore Configuration

Restore factory,import and export settings

Plan task

Perform automatic restart task at fixed time

logs

Logs record

Logs

Network Diagnosis

Network Diagnosis

Ping and Netstat diagnosis

Network Wake

Packaging & Shipping


Package:Blister or color box,K=K Carton

Shipping:By Air,by sea,by Express,LCL,FCL

Payment Condition:30% deposit in advance,70% balance before delivery

Delivery Term:Sample is 1~3days,5days for ready goods,OEM is 30days after deposit

Our Services

Why Choose US?

Brief:

  • Professional with many years experience from 2004
  • Brand:EDUP,Cardking,Wisetiger,SkyWing
  • Most competitive price from material supplier base on huge orders to them
  • Experienced an effective inner cost control system through whole process

Quality Control

  • Raw material test,Online production test,PCS test,finished product test
  • Providing relative solution
  • CE,FCC,RoHS,SGS approved Factory

Service:

  • OEM /ODM service and support
  • Free Sample Development for old customers or customers on Fair
  • Free promotion material if needed
  • Clients service one-to-one
  • Effective communication within 24 hours
  • Attend Hongkong Fair / Carton Fair to meet customer face to face
  • New design and style collection updating for customer
Company Information
FAQ

FAQ

1.What is your advantage?

---Your inquiry will be replied in 24hours

---Well-trained and experienced staffs to answer all your inquires in fluent English

---OEM&ODM, for any of your customized products we can help you to design and put into product

---All our products with 12months guarantee

2.What is our Payment methods?

We agree T/T, Western Union, PayPal.L/C for old customers.

3.What is our Shipping & Trade terms?

Shipping By sea, air, or UPS, FEDEX, EMS, DHL, etc.

Delivered time: 2-3 business days for sample, 20-25 days for mass order.

Trade terms: EXW, FOB , CIF etc.

4. What is our Warranty and Certificates?

Our warranty is 12 months.

We have CE, ROHS, FCC certificates

5.What is your MOQ?

1pc
