Realtek RTL8191su Wireless Wifi USB Adapter 300Mbps For Water Heater / Laptop / Desktop / TV

FOB Reference Price:Get Latest Price
  • 1 - 9 Pieces
    US $5.85
  • 10 - 99 Pieces
    US $5.54
  • 100 - 999 Pieces
    US $5.38
  • >=1000 Pieces
    US $5.23
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
EDUP
Model Number:
EP-MS8512
Transmission:
300mbps
Standard:
802.11n/b/g
Chipset:
Realtek8191su
LED Indicator:
Link/Active ( Green )
Antenna type:
Double 5dBi Antenna
Frequency Band:
2.4GHz ISM
USB2.0:
easy setup
Host Interface:
Mini USB
Antenna:
6dBi antenna
Type:
realtek rtl8191su wifi usb adapter
Supply Ability
Supply Ability:
500000000 Piece/Pieces per Month OEM
Packaging & Delivery
Packaging Details
Weight:0.081
Package Size:19.2*9.6*3.1
Q'ty:100
Carton:49.5*32.5*40
Port
Shenzhen/Hongkong
Lead Time :
Shipped in 3 days after payment

Realtek RTL8191su Wireless Wifi USB Adapter 300Mbps For Water Heater / Laptop / Desktop / TV

Product Description

Product Description

The EP-MS8512 Wireless USB Adapter complies with IEEE 802.11n, IEEE 802.11g, and IEEE 802.11b standards. Wireless transmission rates can reach up to 300Mbps. The adapter employs MIMO technology and has internal Intelligent Antennas providing even better wireless performance, transmission rates, stability and coverage. This product supports 64/128-bit WEP encryptions, as well as WPA/WPA2 encryptions. This product can also simultaneously operate bandwidth intensive applications such as voice, and video. Applications using a lot of bandwidth that are sensitive to interruptions such as voice and video applications are given priority in order to assure quality. It also works well with other 11g and 11n protocol wireless products.If you need usb wifi module to your device,it is also available.

Features

  • IEEE 802.11b/g/n compatible WLAN, Maximum data rate 54Mbps in 802.11g and 150Mbps in 802.11n.
  • Compatible with 802.11n draft 2.0 specification
  • Complies with USB 2.0
  • IEEE 802.11e QoS Enhancement (WMM)
  • IEEE 802.11h TPC, Spectrum Measurement
  • IEEE 802.11i (WPA, WPA2). Open, shared key, and pair-wise key authentication services
  • One Transmit and Two Receive path (1T2R)
  • MIMO technology with stronger signal penetration strength, wider wireless coverage, providing better performance and stability
  • 20/40MHz interoperable channels dramatically increase performance
  • Supports Roaming technology, guaranteeing efficient wireless connections.
  • Supports Wake-On-WLAN via Magic Packet and Wake-up frame
  • Supports Windows 2000/XP/Vista OS
  • DSSS with DBPSK and DQPSK, CCK modulation with long and short preamble
  • OFDM with BPSK, QPSK, 16QAM, and 64QAM modulation. Convolution Coding Rate: 1/2, 2/3, 3/4, and 5/6
  • Programmable scaling in transmitter and receiver to trade quantization noise against increased probability of clipping
  • Fast receiver Automatic Gain Control (AGC)

Specification

Standards

IEEE 802.11n, IEEE 802.11g, IEEE 802.11b,

Wireless Signal Rates With Automatic Fallback

11n: Up to 300Mbps(dynamic)

11g: Up to 54Mbps(dynamic)

11b: Up to 11Mbps(dynamic)

Frequency Range

2.4-2.4835GHz

Wireless Transmit Power

20dBm(MAX)

Modulation Type

OFDM/CCK/16-QAM/64-QAM

Sensitivity

130M: -68dBm@10% PER

108M: -68dBm@10% PER

54M: -68dBm@10% PER

11M: -85dBm@8% PER

6M: -88dBm@10% PER

1M: -90dBm@8% PER

Security

64/128 bit WEP, WPA/WPA2,

Support Operating System

Windows 2000/XP/Vista

Interface

USB 2.0 Hi-Speed

Antenna Type

External 5dBi Antennas

Certifications

CE, FCC, RoHS

Operating temperature

0°C~40°C (32F~104F)

Storage temperature

-40°C~70°C (-40F~158F)

Relative humidity

10% ~ 90%, non condensation

Storage Humidity

5%~95% non-condensing

Pictures


Packaging & Shipping


Package:Blister or color box,K=K Carton

Shipping:By Air,by sea,by Express,LCL,FCL

Payment Condition:30% deposit in advance,70% balance before delivery

Delivery Term:Sample is 1~3days,5days for ready goods,OEM is 30days after deposit

Our Services

Why Choose US?

Brief:

  • Professional with many years experience from 2004
  • Brand:EDUP,Cardking,Wisetiger,SkyWing
  • Most competitive price from material supplier base on huge orders to them
  • Experienced an effective inner cost control system through whole process

Quality Control

  • Raw material test,Online production test,PCS test,finished product test
  • Providing relative solution
  • CE,FCC,RoHS,SGS approved Factory

Service:

  • OEM /ODM service and support
  • Free Sample Development for old customers or customers on Fair
  • Free promotion material if needed
  • Clients service one-to-one
  • Effective communication within 24 hours
  • Attend Hongkong Fair / Carton Fair to meet customer face to face
  • New design and style collection updating for customer
Company Information
QQ20160519084510

Customers and Exhibition

Certificate

FAQ

FAQ

1.What is your advantage?

---Your inquiry will be replied in 24hours

---Well-trained and experienced staffs to answer all your inquires in fluent English

---OEM&ODM, for any of your customized products we can help you to design and put into product

---All our products with 12months guarantee

2.What is our Payment methods?

We agree T/T, Western Union, PayPal.L/C for old customers.

3.What is our Shipping & Trade terms?

Shipping By sea, air, or UPS, FEDEX, EMS, DHL, etc.

Delivered time: 2-3 business days for sample, 20-25 days for mass order.

Trade terms: EXW, FOB , CIF etc.

4. What is our Warranty and Certificates?

Our warranty is 12 months.

We have CE, ROHS, FCC certificates

5.What is your MOQ?

1pc
